W Shape MoSi2 Heating Element 500mm 600mm 700mm Molybdenum Heating Element

Product Details

Place of Origin: China

Brand Name: SONGYU

Payment & Shipping Terms

Minimum Order Quantity: 10pcs

Price: Negotiable

Packaging Details: WOODEN CASE

Delivery Time: 15 work days

Payment Terms: T/T, Western Union

Supply Ability: 10-1000pcs

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                W Shape MoSi2 Heating Element, MoSi2 Heating Element 500mm, 700mm Molybdenum Heating Element


Features:	High Temperature Resistance, Fast Heating, Long Service Life	Voltage:	220V/380V
Heating Zone:	Single/Double	Thermal Shock Resistance:	Good
Diameter:	3/6/9/12mm	Material:	Mosi2 (Molybdenum Disilicide)
Length:	100/200/300/400/500/600/700/800/900/1000mm	Application:	High Temperature Furnace, Vacuum Furnace, Sintering Furnace, Heat Treatment Furnace, Etc.
Surface Load:	5-8W/cm²	Resistance:	1.2-2.5Ω
Shape:	W Shape	Corrosion Resistance:	Excellent
Power:	1-6kW	Max Temperature:	1800°C

Features:	High Temperature Resistance, Fast Heating, Long Service Life
Voltage:	220V/380V
Heating Zone:	Single/Double
Thermal Shock Resistance:	Good
Diameter:	3/6/9/12mm
Material:	Mosi2 (Molybdenum Disilicide)
Length:	100/200/300/400/500/600/700/800/900/1000mm
Application:	High Temperature Furnace, Vacuum Furnace, Sintering Furnace, Heat Treatment Furnace, Etc.
Surface Load:	5-8W/cm²
Resistance:	1.2-2.5Ω
Shape:	W Shape
Corrosion Resistance:	Excellent
Power:	1-6kW
Max Temperature:	1800°C

Product Description

W type Mosi2 Heating Element

High temperature oxidation resistance: In an oxidizing atmosphere, due to high-temperature combustion, a dense quartz protective film is formed on the surface of the component to prevent further oxidation of Mosi2. When the temperature of the component exceeds 1700 ° C, the film will melt. It is not suitable for long-term use within the temperature range of 400-700 ° C, otherwise the components will pulverize due to strong oxidation at low temperatures.

Voltage	220V/380V
Heating Zone	Single/Double
Thermal Shock Resistance	Good
Diameter	3/6/9/12mm
Material	Mosi2 (Molybdenum Disilicide)
Length	100/200/300/400/500/600/700/800/900/1000mm
Features	High temperature resistance, fast heating, long service life
Application	High temperature furnace, vacuum furnace, sintering furnace, heat treatment furnace, etc.
