W Shaped MoSi2 Heating Element 1800c Moly Disilicide Heating Elements

Product Details

Place of Origin: China

Brand Name: SONGYU

Payment & Shipping Terms

Minimum Order Quantity: 10pcs

Price: Negotiable

Packaging Details: WOODEN CASE

Delivery Time: 15 work days

Payment Terms: T/T, Western Union

Supply Ability: Spark Industry (Henan) Co., Ltd.

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                mosi2 heating element 1800c, 1800c moly disilicide heating elements, w shaped mosi2 heating element


Features:	High Temperature Resistance, Oxidation Resistance, Long Service Life	Maximum Temperature:	1800℃
Thermal Conductivity:	18-25W/m·K	Diameter:	3/6/9/12mm
Length:	100/200/300/400/500/600/700/800/900/1000mm	Material:	Mosi2
Density:	6.5-7.5g/cm³	Surface Load:	6-12W/cm²
Power:	100/200/300/400/500/600/700/800/900/1000W	Usage:	High Temperature Heating Element For Industrial Furnaces
Thermal Expansion Coefficient:	4.5-5.0×10^-6/K	Maximum Bending Strength:	350MPa
Voltage:	110/220/240V	Shape:	W Shape

Features:	High Temperature Resistance, Oxidation Resistance, Long Service Life
Maximum Temperature:	1800℃
Thermal Conductivity:	18-25W/m·K
Diameter:	3/6/9/12mm
Length:	100/200/300/400/500/600/700/800/900/1000mm
Material:	Mosi2
Density:	6.5-7.5g/cm³
Surface Load:	6-12W/cm²
Power:	100/200/300/400/500/600/700/800/900/1000W
Usage:	High Temperature Heating Element For Industrial Furnaces
Thermal Expansion Coefficient:	4.5-5.0×10^-6/K
Maximum Bending Strength:	350MPa
Voltage:	110/220/240V
Shape:	W Shape

Product Description

W type Mosi2 Heating Element

The W-shaped MoSi2 heating element is a revolutionary heating solution that sets new standards in the industry. Its unique design and advanced materials make it highly efficient and durable. The molybdenum disilicide material offers excellent resistance to thermal shock and oxidation. The W-shape provides a larger heating surface area, enabling faster heating and more uniform temperature distribution. This heating element is easy to operate and maintain, saving time and effort. Whether used in research laboratories or industrial production lines, it delivers outstanding heating performance.

Atmosphere	SP1700	SP1800
Air	1700	1800
N2 Nitrogen	1600	1700
Ar Ne Argon,Helium	1600	1700
Dry Hydrogen(dew point)-80°C	1150	1150
Wet Hydrogen(dew point)-20°C	1450	1450
Exogas(e.g.10% CO2,50%CO,15%H2)	1600	1700
Exogas(e.g.40%CO2,20%CO)	1400	1450
Cracked and partially burnt ammonia	1400	1450
