1600C SiC Heating Element 4kW 4.5kW 5kW Silicon Carbide Heating Element Furnace

Product Details

Place of Origin: China

Brand Name: SONGYU

Payment & Shipping Terms

Minimum Order Quantity: 10pcs

Price: Negotiable

Packaging Details: WOODEN CASE

Delivery Time: 15 work days

Payment Terms: T/T, Western Union

Supply Ability: Spark Industry (Henan) Co., Ltd.

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                1600c sic heating element, sic heating element 4kw, 5kw silicon carbide heating element furnace


Shape:	U Shape	Terminal Type:	Threaded, Non-threaded
Max. Working Temperature:	1600°C	Heating Zone:	Single Zone, Double Zone, Three Zone
Voltage:	220V, 380V, 400V, 480V	Thermal Conductivity:	14W/m·K
Diameter:	9mm, 12mm, 14mm, 16mm, 18mm, 20mm, 25mm	Cold End Length:	150mm, 200mm, 250mm, 300mm, 350mm, 400mm, 450mm, 500mm
Terminal Material:	Molybdenum Disilicide (MoSi2)	Power:	1.5kW, 2kW, 2.5kW, 3kW, 3.5kW, 4kW, 4.5kW, 5kW, 6kW, 7kW, 8kW, 9kW, 10kW
Resistance:	1.2Ω, 1.5Ω, 1.8Ω, 2.2Ω, 2.6Ω, 3.0Ω, 3.5Ω, 4.0Ω, 4.5Ω, 5.0Ω, 6.0Ω, 7.0Ω, 8.0Ω	Maximum Surface Load:	9W/cm²
Length:	300mm, 400mm, 450mm, 500mm, 550mm, 600mm, 650mm, 700mm, 750mm, 800mm, 850mm, 900mm, 950mm, 1000mm	Hot Zone Length:	150mm, 200mm, 250mm, 300mm, 350mm, 400mm, 450mm, 500mm

Shape:	U Shape
Terminal Type:	Threaded, Non-threaded
Max. Working Temperature:	1600°C
Heating Zone:	Single Zone, Double Zone, Three Zone
Voltage:	220V, 380V, 400V, 480V
Thermal Conductivity:	14W/m·K
Diameter:	9mm, 12mm, 14mm, 16mm, 18mm, 20mm, 25mm
Cold End Length:	150mm, 200mm, 250mm, 300mm, 350mm, 400mm, 450mm, 500mm
Terminal Material:	Molybdenum Disilicide (MoSi2)
Power:	1.5kW, 2kW, 2.5kW, 3kW, 3.5kW, 4kW, 4.5kW, 5kW, 6kW, 7kW, 8kW, 9kW, 10kW
Resistance:	1.2Ω, 1.5Ω, 1.8Ω, 2.2Ω, 2.6Ω, 3.0Ω, 3.5Ω, 4.0Ω, 4.5Ω, 5.0Ω, 6.0Ω, 7.0Ω, 8.0Ω
Maximum Surface Load:	9W/cm²
Length:	300mm, 400mm, 450mm, 500mm, 550mm, 600mm, 650mm, 700mm, 750mm, 800mm, 850mm, 900mm, 950mm, 1000mm
Hot Zone Length:	150mm, 200mm, 250mm, 300mm, 350mm, 400mm, 450mm, 500mm

Product Description

W Type SiC Heating Elements

W-shaped silicon carbon rods are suitable for various electric furnaces and kilns, especially for electric heating elements in high-temperature kilns. Its surface temperature can reach 1500 ℃, with uniform redness and strong infrared radiation ability, 5-10 times that of ordinary nickel chromium wire. In addition, the W-shaped three-phase silicon carbide rod can be directly connected to the three-phase power supply, making it convenient for one-way wiring on the furnace top and ensuring safety and reliability during use.

Maximum Load	30kg
Power	2.5kW
Shape	W Shape
Maximum Operating Temperature	1600°C
Hot Zone Length	200mm
Material	Silicon Carbide
