M Type SiC Heating element

Product Details

Place of Origin: China

Brand Name: SONGYU

Payment & Shipping Terms

Minimum Order Quantity: 10pcs

Price: Negotiable

Packaging Details: WOODEN CASE

Delivery Time: 15 work days

Payment Terms: T/T, Western Union

Supply Ability: Spark Industry (Henan) Co., Ltd.

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                220v sic heater, 1500w sic heater, 220v sic heating element


Features:	High Temperature Resistance, Oxidation Resistance, Long Service Life	Material:	Silicon Carbide
Voltage:	220V	Length:	300mm
Diameter:	6mm	Application:	High Temperature Heating
Resistance:	1.2Ω	Power:	1500W
Density:	2.6g/cm³	Max Temperature:	1600°C
Thermal Conductivity:	120 W/m·K	Shape:	Rod
Working Atmosphere:	Air, Vacuum, Inert Gas	Type:	M Type

Features:	High Temperature Resistance, Oxidation Resistance, Long Service Life
Material:	Silicon Carbide
Voltage:	220V
Length:	300mm
Diameter:	6mm
Application:	High Temperature Heating
Resistance:	1.2Ω
Power:	1500W
Density:	2.6g/cm³
Max Temperature:	1600°C
Thermal Conductivity:	120 W/m·K
Shape:	Rod
Working Atmosphere:	Air, Vacuum, Inert Gas
Type:	M Type

Product Description

M Type SiC Heating element

Chlorine gas (Cl2) reacts with SiC above 100 ℃, and completely decomposes SiC above 1200 ℃. The aging of silicon carbide rods. Silicon carbide rods are used for a long time at high temperatures, and due to the oxidation of the SiC surface, the SiO2 content in the components gradually increases, causing an increase in their resistance. This is a normal phenomenon called "aging". During the first 500 hours of use, the aging rate of the components is fast, and the aging rate is slow thereafter, mainly because the SiO2 film on the surface of the components slows down the oxidation of SiC. The aging rate of silicon carbide rods depends on the operating temperature and surface load density of the components. To maintain a constant power of the silicon carbide rod and achieve ideal furnace temperature, it is necessary to use corresponding voltage regulators to adapt to the increasing resistance of the components during use.

Density	2.6-2.8g/cm3
Diameter	6mm
Length	300mm
Shape	Rod
Operating Temperature	1200-1500°C
Material	Silicon Carbide
