Double Threaded Silicon Carbide Rod SiC Heating Element 300mm Length

Product Details

Place of Origin: China

Brand Name: SONGYU

Payment & Shipping Terms

Minimum Order Quantity: 10pcs

Price: Negotiable

Packaging Details: WOODEN CASE

Delivery Time: 15 work days

Payment Terms: T/T, Western Union

Supply Ability: Spark Industry (Henan) Co., Ltd.

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                silicon carbide rod sic, sic heating element 300mm, double threaded silicon carbide rod


Length:	300mm	Maximum Surface Load:	9W/cm²
Hot Zone Length:	75mm	Max. Working Temperature:	1600°C
Diameter:	12mm	Chemical Composition:	SiC ≥ 98%, Free Si ≤ 0.5%
Heating Zone Length:	150mm	Resistance At 20°C:	1.2Ω
Flexural Strength:	≥400MPa	Porosity:	≤15%
Thermal Conductivity:	≥45W/m·K	Cold Zone Length:	75mm
Shape:	U Shape	Bulk Density:	2.7g/cm³

Length:	300mm
Maximum Surface Load:	9W/cm²
Hot Zone Length:	75mm
Max. Working Temperature:	1600°C
Diameter:	12mm
Chemical Composition:	SiC ≥ 98%, Free Si ≤ 0.5%
Heating Zone Length:	150mm
Resistance At 20°C:	1.2Ω
Flexural Strength:	≥400MPa
Porosity:	≤15%
Thermal Conductivity:	≥45W/m·K
Cold Zone Length:	75mm
Shape:	U Shape
Bulk Density:	2.7g/cm³

Product Description

SGR Type SiC Heating Elements

Double threaded rod is an electronic component made by precision calculation and special processing on the basis of U-shaped silicon carbide rod. It is designed to meet the needs of electric furnaces with small furnace space that cannot install normal U-shaped silicon carbide rod, and the temperature can reach 1500. Mainly used for heating kilns with special needs, its characteristics are: more energy-efficient, easy to operate, high operating temperature, and long service life.

Density	2.6-2.8 g/cm3
Product Type	Heating Elements
Resistance	1.2-2.5 Ohms
Maximum Power	500-3000 Watts
Max. Working Temperature	1600°C (2912°F)
Thermal Conductivity	100-120 W/m·K
